ECG Electrode Polyethylene IXPE Cross Linked PE Foam

Product Categories

Cyg Tefa Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Brand Name : CTF

Certification : Reach, RoHS

Place of Origin : Guangdong, China (Mainland)

MOQ : 5000 Square Meter/Square

Price : negotiable

Payment Terms : T/T, L/C

Supply Ability : 500 tons per month

Delivery Time : 15 - 20 work days

Packaging Details : Wasted PE Foam + PE Bag

Thickness : 0.1mm to 50mm

Feature : Flexible

Material : IXPE Foam

Port : shenzhen

Density : 25kg/m3 to 333kg/m3

Type : sheets/rolls

Size : Custom Size,on demand

Contact Now

Cross Linked PE Foam Polyethylene IXPE Foam ECG Electrode

Application of IXPE Insulation Material:

– Medical area

- ECG Electrode

- Could be with or without adhesive

Product Detail

3.Product Testing

For example: 96kg/m3 1mm

Property		Standard	Unit	Value
Density		-	Kg/m³	96.00
Tensile Strength	Transverse	ISO-1798	MPa	0.70~0.71
	Longitudinal			0.89~0.91
Elongation	Transverse	ISO-1798	%	188.20~192.10
	Longitudinal			199.30~202.50
Tearing Strength	Transverse	ISO-8067	Kn/m	3.76~4.28
	Longitudinal			4.76~4.80
Compression 25%		ISO-3386-1	kPa	102.80
Compression 40%		ISO-3386-1	kPa	152.00
Compression 50%		ISO-3386-1	kPa	203.20
Compression Set 25% 0.5H		ISO-1856	%	13.60
Compression Set 25% 24H		ISO-1856	%	5.20
Operating Temperature Range		Internal	°C	(-40,+80)
Water Absorption % Volume (Maximum)		Internal	%	0.30
Thermal Conductivity		JIS A1412-2	W/mK	0.073
Shore - C		ASTM D2240	°C	46

4.Product Application

ECG Electrode, Flooring underlayment, Bottle cap, Foam tape, Sealing tape, etc.

ECG Electrode Polyethylene IXPE Cross Linked PE Foam
